Bincolor BC-962 High Frequency 2CH Power Repeater DC5-24V Led Controller

Be the first to review this product

Availability: In stock

€20.99
  • OR

    Quick Overview

    Bincolor BC-962 High Frequency 2CH Power Repeater DC5-24V Led Controller

    Bincolor BC-962 High Frequency 2CH Power Repeater DC5-24V Led Controller

    Double click on above image to view full picture

    Zoom Out
    Zoom In

    More Views

    Details

    LED Power Repeater is suitable for all of our company's power-output style controllers' power expansion, it accepts PWM control, unlimited quantity of power repeater to be connected theoretically. Also, the power repeater of constant voltage model and constant current model could be connected freely, suitable for synchronized controlling on different LED lamps.

    Feature function:

    Common anode input and output.

    Sustain high frequency common anode PWM input signal.

    Work with RGB controller, DMX512 decoder, LED dimmer for synchronous control, to fulfill abundant color changings.

    Over current protection and short circuit protection.

    3000V optoelectronic isolation.

    Model Number: BC-962

    Input power: DC5V-DC24V

    Maximum load current: 8A/CH × 2

    Output signal: Constant voltage PWM

    The maximum output power: 80W(5V)192W(12V)384W(24V)

    Product Size: L176×W46×H30(mm)

    Packing size:  L178×W48×H35(mm)

    Product weight : 120g

    Package Include:

    1 Piece of Bincolor BC-962 High Frequency 2CH Power Repeater DC5-24V Led Controller
    Bincolor_Controller_BC_962_1
    Bincolor_Controller_BC_962_2
    Bincolor_Controller_BC_962_3
    Bincolor_Controller_BC_962_4
    Bincolor_Controller_BC_962_5
    Bincolor_Controller_BC_962_6
    Bincolor_Controller_BC_962_7

    CE and RoHS approved

    Additional Information

    Weight 0.3200
