Details
100W 24V DC LED Constant Voltage Euchips Triac Dimmable Driver DIM107H-24
Product Description
100W 24VDC CV Triac Driver
Item: DIM107H-24
Output Power:100W
Output Current:4.5A max
Output Voltage:DC24V
Size:200*98*39mm
Features
Collect cut-phase signal by digital means, to ensure dimming consistancy between individuals
24VDC constant voltage output, max current MAX4.5A
Dimming range from 40-240VAC, dimming curve smooth
Protections: short circuit, over load
100% full load burn-in test
Support leading edge(Triac) and Trailing edge(ELV) dimmer. To change input voltage via phase cut, in order to achieve perfect effect, please select dimmer properly
Has power indicate LED
Package Include:
1 Piece of 100W 24V DC LED Constant Voltage Euchips Triac Dimmable Driver DIM107H-24
1 Piece of Product's Manual
CE and RoHS approved
Additional Information
Weight | 0.6730 |
---|
