Details
led WiFi controller,1 port control maximum 2048 pixels,support WS2811,WS2812,DMX512,etc.Controlled by android phone via WLAN. Can switch files, adjust speed and brightness and doodle on phone.
1. Introduction
H806SB is controlled by Android Phone via WiFi, it supports dozens of single-line and double-line chips and drives maximum 2048 pixels.
2. Support Chips
LPD6803, LPD8806, LPD1882, LPD1889, LPD6812, LPD1883, LPD1886, DMX512, HDMX, APA102, MY9221, UCS6909, UCS6912, UCS1903, UCS1909, UCS1912, UCS8904, WS2801, WS2803, WS2811, WS2812, TM1803, TM1804, TM1809, TM1812, TM1829, TA9912, TM1913, TM1914, TM1926, TM1814, INK1003, LX1003, LX2003, LX2006, TLS3001, P9813, P9816, SM16711, SM16716, LD151x, LD153x, MBI6021, MBI6023, MBI6024, etc.
3. Performance
(1). One port controls maximum 2048 pixels.
(2). You can use four buttons on controller or Android phone to switch files, adjust speed and brightness or set “single playback” or “circle playback”.
(3). You can use phone to export text, image or doodle.
(4). DC5V or DC9~24V input.
Package Included:
1 Piece of 2048 Pixels SD Card Controller
1 piece of 128MB SD Card
1 Piece of User's Manual
CE and RoHS approved
Additional Information
Weight | 0.3000 |
---|
