Ltech LT-8036-1000 Dmx Rdm CC Decode Dimmer Decoder Circuit Board Led Controller Driver Control
LT-8036-1000
Name DMX/RDM CC decode circuit board
Input signal DMX512, RDM
Input voltage 12~36Vdc
Output voltage 7.5~33Vdc
Output current CC 1000mA × 4CH
Output power (0~7.5W...33W) × 4CH Max. 132W
Dimming range 0~100%
Control mode Dimming/CT/RGB/RGBW
Working temperature -30℃～65℃
Dimension L155 × W26 × H10(mm)
Weight (G.W) 30g
Package Include:
1 Piece of Ltech LT-8036-1000 DMX RDM CC Decode Circuit Board LED Controller
CE and RoHS approved
