Details
4”×2” miniature size
Universal AC input / Full range
Built-in active PFC function
EMI Class B for both Class Ⅰ(with FG) and Class Ⅱ(without FG) configuration
Medical safety approved(2 × MOPP between primary to secondary)
Suitable for BF application with appropriate system consideration
Low leakage current<190μA
No load power consumption<0.5W
High efficiency up to 94%
Protections: Shout circuit / Overload / Over voltage / Over temperature
Cooling by free air convection for 140W and 200W with 10CFM forced air
Built-in 12V/0.5A fan supply
LED indicator for power on
3 years warranty
Package Includes:
1 Piece of RPS-200 200W Mean Well Single Output Green Medical Type Power Supply
CE and RoHS approved
Additional Information
Weight | 0.2900 |
---|
